35″ Eye & Eye Zinc Coated Steel Turnbuckle

Description

Part # 5340-00-187-8194

Military Surplus 35" Eye & Eye Turnbickle.
NSN: 5340-00-187-8194

• Thread Class: 1B body
• Body Style: Flat open buckle
• EYE Width: 1.438 inches nominal
• END Style: Closed eye and closed eye
• Length: 35.000" nominal
• Body Length: 27.000" nominal
• Take-UP Distance: 24.000" nominal
• Locking Device Type: NUT
• Nominal Thread Size: 1.000" body
• Body Material: Steel
• End Pull Material: Steel
• Surface Treatment: Zinc overall
• Thread Series Designator: Unc body
